Descripción
| Parámetro | Valor |
|---|---|
| Fluid | Air |
| Proof pressure | 218 PSI |
| Max. operating pressure | 145 psi |
| Min. operating pressure | 14.5 psi |
| Ambient and fluid temperature | 23 to 140°F (-5 to 60°C) |
| Aplicable tubing material | Nylon, soft nylon, Poliurethane, FEP, PFA |
| Body | 1002 | 2002 | 3002 | 4002 |
